| ब्रांड नाम: | GBS |
| मॉडल संख्या: | GBSFP51200T |
| एमओक्यू: | 1 टुकड़ा |
| कीमत: | negotiable |
| भुगतान की शर्तें: | एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम |
| आपूर्ति करने की क्षमता: | 1800000 पीसीएस प्रति वर्ष |
| Parameter | Value |
|---|---|
| Nominal voltage | 51.2VDC |
| Nominal capacity | 200Ah |
| Battery energy | 10.24KWh |
| Cutoff charge voltage | 57.6V |
| Cutoff discharge voltage | 46.4V |
| Fast Charge Current | 200A |
| Maximum Discharge Current | 200A |
| Maximum charge power | 10KW |
| Maximum discharge power | 10KW |
| Short circuit current | 504A |
| Display | SOC status indicator, LED indicator |
| Communication | RS485, CAN |
| Dimension (W×D×H) | 450×229×650mm |
| Weight | 92kg |
| Installation | Ground mounted or wall mounted |
| Working temperature | Charge: 0~65℃, Discharge: -20~65℃ |
| Storage temperature | -20~45℃ |
| Relative Humidity | 5%~95% |
| Maximum operating altitude | 4000m |
| IP rating | IP20 |
| Cell type | LiFePO4 |
| Cycle life | 6000 cycles @ 80% DOD/25℃/0.5C |
| Scalability | Max 15 batteries in parallel |
